Products discription | ||||
---|---|---|---|---|
Model Number: | 131.10.1400 | Brand name | longwei | |
Production Experience | Since 2004 | Applicable Industries: | Military,Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory | |
Feature: | CROSS ROLLER | Gear Options: | External Gear | |
Material: | 50Mn/42CrMo/Customized | Seals Type: | Nitrile Rubber or as requirement | |
MOQ | 1 set | CERTIFICATE: | ISO9001:2008/SGS | |
Bore Diameter | 1205 mm | Outside Diameter | 1595mm | |
Operating tempereature: | -30°C +70°C | Hardness: | 55-62HRC | |
Product Name: | single row ball with External Gear Slewing Bearing | Service: | OEM Service.Design Service | |
Net Weight : | 1200kgs | Rolling element: | steel ball & Spacer | |
Warranty Period | 1 year | Testing | In house or third party | |
MOQ | 1 SET | Size | Standard OR Customized | |
Height | 220 mm | H.S. Code | 848210900 | |
Packaging Details | 1.Filling with rust-proof oil 2.packing with protective layers 3.Fixed in the plywood 4.Packaging terms:Plywood case/ Pallet/Steel frame | Product Type: | Three Row Roller | |
131.40.1400 Technical | parameter | |||
Model | Dimensions | Installation Size | Structure Size | Gear data |
131.40.1400 | D - 1595mm | n - 45 | n1 - 5 | x-0.5 |
Slewing Bearing | d - 1205mm | Φ - 26mm | D3 - 1450mm | M-12/14 |
External Gear | H - 220mm | dm - M24 | d1 - 1437mm | De-1665.6 |
N.W. 1200KG | D1 - 1543mm | L - 48mm | H1 - 210mm | z-136 |
D2 - 1257mm | h - 50mm |
The three row roller slewing bearing has three row raceway, the rolling element is steel roller. This structure could bear the heaviest load comparing to other structure bearing type. Usually the triple row roller slew bearing is used for some heavy duty machinery. Three-Row Roller Slewing Ring is equipped with seat-rings, upper orbit. Neither orbit and radial orbit is separated individually, it makes the load of each row of the rollers can be confirmed, making it can undertake all kinds of different load simultaneously. Three row roller slewing bearing’s carrying capacity is the biggest among four models and the axial and radial size are rather large to some extent, the structure of the three row roller slewing bearing ring is very firm.
the catalogue for the three row roller slewing bearing with External gear
![the-catalogue-for-the-three-row-roller-slewing-bearing-with-External-gear](https://www.islewingbearing.com/wp-content/uploads/2023/07/the-catalogue-for-the-three-row-roller-slewing-bearing-with-External-gear.jpg)
>>Note
- n1 is the nos of lubricating holes.Oil cup M10×1JB/T7940.1~JB/T7940.2.The Oil nipple’s location can be change according to the user’s application.
2. n-φcan change to tapped hole,the diameter of tapped hole is M,depth is 2M.
3. The tangential tooth force in the form is the max tooth force,the nominal tangential tooth force is 1/2 of the max one.
4. “K” is addendum reduction coefficient.
Longwei Transmission Slewing Bearing Co.,Ltd. is a slewing bearing manufacturer specializing in standard and non-standard slewing bearing.Over the years, we supplied high quality product & good service to every user and gain good credit.We have strict quality control system in our own factory,meanwhile, we have passed ISO9001-2008
Gear Heat Treatment
Special heat treatment design is carried out according to the different needs of specific industries for gears, mainly including induction single-tooth quenching and induction-type integral tooth quenching. Single tooth quenching is divided into tooth surface quenching and tooth surface and root quenching. After quenching, tempering treatment is carried out to make the surface hardness and the depth of the hardened layer meet the design standards. The most advantageous process is the special process of integral tooth quenching, which can improve the transmission efficiency and increase the wear resistance and impact resistance of the tooth surface, so as to meet the needs of customers.
The raceway heat treatment of the slewing bearing is realized by induction heat treatment technology. Longwei Slewing Bearing has advanced heat treatment equipment (processing equipment and testing equipment) and scientific processing technology, so that the depth and hardness of the hardened layer conform to JB /T2300-2018 slewing bearing standard.
